CD 800 Controls and Installation CD 800 Controls and Installation
Controls and Installation, cont’d
2-4
6 — H+ (positive H sync output polarity)
On — Horizontal sync polarity is positive.
Off — Horizontal sync polarity is negative.
7 — V+ (positive V sync output polarity)
On — Sync polarity is positive.
Off — Sync polarity is negative.
8 — X MODE (executive mode)
On — Front panel picture controls are disabled,
preventing any adjustments. Both Min
and Max LEDs light in executive mode.
Off — Adjustments to picture controls can be
made via the front panel.
5 Red (R) — BNC connector for red video output.
6 Green (G) — BNC connector for green video output.
7 Blue (B) — BNC connector for blue video output.
8 H/HV — BNC female connector for either separate
horizontal (H) sync if 5-wire (RGBHV), or composite
sync (HV) for 4-wire (RGBS). See Sync switch (9).
9 Sync switch — Set the 3-position switch to one of the
following:
H — Top position, for RGBHV output, or 5-wire
output. The horizontal sync is on the H
connector, and vertical sync is on the V
connector.
H/V — Middle position, for RGBS output, or 4-wire
composite output. Horizontal and vertical sync
are combined on the single H/HV output
connector.
SOG — Bottom position, for SOG (RGsB), or 3-wire
output. Horizontal and vertical sync are on the
green video signal (G) output.
10 V — Used for separate vertical sync output when the
Sync switch (9) is in the H position.
11 RS-232 and contact closure control — This 9-pin D
female connector is used to attach a computer or
other host, or contact closure device, for remote
control of the CD 800.
See page 3-2 for information about the RS-232 port,
and 3-6 for information about the remote contact
closure control.
Installation
Overview
To install and set up the CD 800, follow these basic steps:
1 Turn all of the equipment off. Make sure that the
video sources (composite and/or S-video device), the
CD 800, the output device (projector or monitor) and
contact closure control device are turned off and
disconnected from the power source.
2 Mount the CD 800. See “Mounting the CD 800”
below.
3 Attach the cables. See “Cabling” on page 2-7 or, if
you are connecting the CD 800 to a system switcher
in video loopback mode, see “Cabling for video
loopback” on page 2-8.
4 Connect power cords and turn on the devices in the
following order: output device, contact closure
controller, CD 800, and input devices.
5 Select an input from the front panel buttons or the
contact closure controller.
6 The image should appear. If it does not, ensure that
all devices are plugged in and receiving power.
Check the cabling and make adjustments as needed.
Select a different input to check for an image. Refer
to “Troubleshooting” in this chapter.
Mounting the CD 800
The CD 800 is one unit (1U) high and one-half unit wide. It
can be used as a freestanding unit or installed on a 1U
universal rack shelf (Extron part #60-190-01).
Follow these steps to install the CD 800 on a rack shelf:
1. Remove rubber feet from the bottom of the CD 800.
2. Place the CD 800 on the rack shelf. Align the front of
the CD 800 with the front of the shelf, and align the
threaded holes on the bottom of the decoder with the
holes in the rack shelf.
