CD 800 Specifications CD 800 Specifications
Specifications, cont’d Specifications
A-3 A-2
Video input
Number/type ............................... 1 S-video (Y/C), 1 composite video
(switch-selectable)
Connectors .................................... 1 4-pin mini-DIN female (S-video)
1 BNC female (composite video)
Nominal level(s) .......................... Analog — 0.7V to 1V p-p
Impedance .................................... 75 ohms
Horizontal frequency ................. 15.6 kHz to 17.75 kHz
Vertical frequency ....................... 50 Hz to 60 Hz
Video throughput
Gain ............................................... Variable by adjusting contrast
Bandwidth .................................... 6 MHz (-3 dB) (luminance)
Differential phase error .............. 1.5º, 0 to 10 MHz
Differential gain error ................ 1.5%, 0 to 10 MHz
Video output
Number/type/format ................ 1 RGBHV, RGBS, RGsB (toggle switch-
selectable)
Connectors .................................... 5 BNC female
Nominal level ............................... Analog — 0.7Vp-p, DC coupled
Impedance .................................... 75 ohms
DC offset ....................................... ±0.1V maximum
Sync
Output type .................................. RGBHV, RGBS, RGsB (toggle switch or
Windows program control selectable)
Standards ...................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Input level ..................................... 0.3V p-p
Output level ................................. TTL — 5V p-p
Input impedance ......................... 75 ohms
Output impedance ...................... 75 ohms
Polarity ........................................... RGBHV ........................ positive or negative
(switch-selectable)
S-video ......................... negative
Composite video ........ negative
Control/Remote — decoder
Serial control port ....................... RS-232, 9-pin female D connector
Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity
Pin configurations ....................... 2 = TX, 3 = RX, 5 = GND
Contact closure ............................ 9-pin female D connector
Program control ........................... Extron’s control program for Windows
Extron’s Simple Instruction Set (SIS)
General
Power ............................................ 100VAC to 240VAC, 50/60 Hz,
7.5 Watts, internal, auto-switchable
Temperature/humidity ............. Storage -40° to +158°F (-40° to +70°C) /
10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing
Rack mount .................................. Yes, with optional rack shelf,
part #60-190-01
Enclosure type ............................. Metal
Enclosure dimensions ................ 1.75" H x 8.75" W x 9.5" D
4.45 cm H x 2.22 cm W x 24.13 cm D
Shipping weight .......................... 5 lbs (2.3 kg)
Vibration ....................................... NSTA 1A in carton
(National Safe Transit Association)
Approvals ..................................... UL, CE
MTBF ............................................. 30,000 hours
Warranty ....................................... 2 years parts and labor
Specifications are subject to change without notice.
