Operating principles ProLab 3000
34 ba75645e03 12/2012
Display Depending on the operating situation, the color display shows mea-
surement data, calibration steps, setting dialogs or stored data.
Main menu (1)
In the main menu, there are sensor independent functions and settings:
 Manage configurations (File ) (see page 166)
 Store current measurement data, and display and edit stored mea-
surement and calibration data (Memory) (see page 137)
 System settings such as language, date, time, color assignment,
interface settings and general measurement settings (System) (see
page 56)
 Select the measurement data to be displayed (Window)
 Manage user data (User ) (see page 147)
1 Main menu
2 Channel
3 Menu for a measured parameter
5 Info line
6 Softkey assignment
12 Softkeys
1
2
3
6
12
5
