Technical data MIQ/CHV PLUS
7 - 4 ba76036e01 01/2012
Valve circuits
Warning
The valve circuit must not supply any unauthorized voltages or
currents. It has to be made sure that the circuit at any time meets
all requirements of a Limited circuit or Limited Power as well as of
SELV (Safety Extra Low Voltage). These include the following
limiting value specifications:
 AC voltage: max. 30 V effective / 42.4 V peak
 DC voltage: max. 60 V

Current limit: max. 8 A
 Power output limitation: max. 150 VA
Compressed air
Switching voltage Approx. 12 V
Max. switching current Approx. 70 mA
Required air quality Dry, dust-free and oil-free
Operating pressure Max. 7x10
5
Pa (7 bar) absolute
Connections 6 mm hose nozzles
