Outputs System 182 XT-4
6 - 2 ba76026e01 01/2012
Functions for current
outputs
 Recorder
 PID controller
 Fixed current value
Note
You can view the current states of the relay and current outputs in the
measured value and status display (see section 4.2).
Valve outputs
(MIQ/CHV PLUS)
The MIQ/CHV PLUS valve module is administrated by the system as a
valve output (designation, MIQ/CHV PLUS V1). The relevant setting
tables are available via the SETTINGS menu.
Note
The installation and settings of the valve module are described in the
operating manual of the MIQ/CHV PLUS.
