Xylem HandyLab 750(EX) - Manual (Page 49)

49
49
Data Logger
Overview of data logger menu (default in bold print)
Logger
type DIFF Delta pH /
mV OFF / pH 0.01…14.00 / pH 1.00
OFF / 1… 1000 mV / 1 mV
Delta °C / °F OFF / 0.1 … 50.0 °C / 1.0 °C
OFF / 0.1 …90 °F / 1.0 °F
INT Interval h:mm:ss
0:00:01 … 9:59:59 / 0:01:00
DIFF
+INT DIFF See logger type DIFF
INT See logger type INT
SHOT Currently selected process variable is recorded
Data Logger Menu
Logger display Select using arrow keys, confi rm by pressing
set
.
CONT Select start address and start the data logger
START Deletes all entries and starts the data logger at
start address 0001
DEL Deletes all entries
SET Select logger type and confi gure:
DIFF, INT, DIFF+INT, SHOT (see table below)
