Technical Reference
Pump station numbering system
The pump station label located on the inside of the control enclosure door identifies the
product code number for the various versions of the pump systems. This number is also
the catalog number for the pump station. The pump station numbering systems describe
the meaning of each digit.
Not all combinations are possible.
Pump station with e-SV pumps
Example product code
V 2 VF C 2 A 2 1 A 1 BCD
Numbering system definitions
First character: Variable or constant speed
V = variable speed
C = constant speed
Second character: Number of pumps
2, 3, or 4
Third character: Pump type and size
VA = 1SV
VG = 33SV
VB = 3SV VH = 46SV
VC = 5SV VJ = 66SV
VD = 10SV VK = 92SV
VE = 15SV VM = 125SV
VF = 22SV
Fourth character: Header size
C = 3 in.
E = 6 in.
D = 4 in. F = 8 in.
Fifth character: Supply voltage
2 = 208 V / 1 PH / 60 Hz
6 = 460 V / 3 PH / 60 Hz
3 = 230 V / 1 PH / 60 Hz 7 = 575 V / 3 PH / 60 Hz
4 = 208 V / 3 PH / 60 Hz 8 = 380 V / 3 PH / 60 Hz
5 = 230 V / 3 PH / 60 Hz 9 = 380 V / 3 PH / 50 Hz
Sixth character: HP rating
A = 1/2
E = 2 J = 10 N = 30 T = 75
B = 3/4 F = 3 K = 15 P = 40 U = 100
C = 1 G = 5 L = 20 R = 50 V = 125
D = 1-1/2 H = 7-1/2 M = 25 S = 50 W = 150
