• Serial number
• Item numbers of the required parts.
Date Code
Pump Boost
Discharge Pressure
Suction Pressure
Station Flow
Largest Motor HP
SCCR
System FLA
Station Voltage
Serial Number
Model Number
Applied Water Solutions
Dallas, Texas, U.S.A .
Customer Service 1.800.786.7480
Nameplate field Explanation
Model number The manufacturer's number to indicate the particular type of product which has been
acquired.
Serial number A set of characters that uniquely identifies a single unit and can be used for
traceability and warranty purposes.
Station voltage The rated voltage at which the station has been designed for. Should match the
application site supply voltage.
System FLA The full-load-amperage at which the station can operate.
SCCR “Short-Circuit Current rating”. Represents the maximum level of short-circuit current
that a component or assembly can withstand.
Largest motor HP The rated HP for the largest pump in the system.
Station flow The designed duty point, in GPM, LPH, etc.
Suction pressure inlet The line pressure on the input side of the pump station.
Discharge pressure The line pressure on the output side of the pump station
Pump boost The difference between the input side of the pump station and the output side of the
pump station.
Date code Marking of products to indicate their date of manufacture.
Product Description
