Backplane board and jumper settings

No.

Code

Description

1

J2

SMBUS connector
Connects to mainboard or RAID card

2

J1

SMBUS (W83792D) connector
Connects to enclosure IC

3

CN1/X1

Power connector

4

CN2/X2

Power connector
