Acer AT310 F1 User Manual
Page 30
1 System tour
12
20
SATA4
SATA 4 port
21
SATA5
SATA 5 port
22
CASE_OPEN
Chassis intrusion header
23
CLR_CMOS1
Clear CMOS jumper
24
USB1
Front USB1 cable connector
25
USB2
Internal USB connector
26
F_PANEL
Front panel connector
27
COM2
Connects to serial port
28
PCI5
PCI slot (32-bit/33 MHz, 3.3 V)
29
PCI4
PCI-E x8 slot (x4 signal)
30
PCI3
PCI-E x16 slot (x8 signal)
31
PCI2
PCI-E x4 slot (x1 signal)
32
U28
BMC controller
33
PCI1
PCI-E x8 slot (x8 signal)
34
FAN2
System fan 2 cable connector
Connects to the rear system fan
35
FAN4
System fan 4 cable connector
No.
Code
Description
