55
Installing an BMC module
The optional BMC module allows system administrators to manage the
Altos R5250 system remotely over a network.
To install a BMC module:
1 Perform the pre-installation instructions described on page 28.
2 Remove the SAS daughter board.
(1) Detach any cables attached to the SAS daughter board.
(2) Remove the screw that secures the board to chassis (A).
(3) Gently pull the SAS daughter board to remove it from the
daughter board slot (B).
3 Remove the BMC module from its protective packaging.
4 If necessary, install the two plastic standoffs to the holes on the
mainboard.
