Electrical Characteristics
(@T
A
= +25°C, V
IN
= V
O
+0.5V, V
CTRL
= V
EN
= 5V, C
IN
= C
O
= 10µF, unless otherwise specified.)
Parameter Symbol Test Conditions Min Typ Max Units
Input Voltage Range V
IN
2.5 5.5 V
Output Voltage Accuracy V
O
I
O
= 1mA to 1.5A -1.5 1.5 %
Dropout Voltage V
DROP
I
O
= 500mA V
O
≥ 2.5V 200
mV
I
O
= 1.5A V
O
≥ 2.5V 400
Short Circuit Current I
SC
V
O
< 0.3V 500 mA
Quiescent Current I
Q
I
O
= 0mA 75 150 µA
Current Limit I
LIM
2 A
Line Regulation LNR
V
O
≤ 2.5V, I
O
= 10mA
V
IN
= V
O
+1.5V to V
O
+2.5V
0.5 1 %/V
V
O
> 2.5V, I
O
= 10mA
V
IN
= V
O
+0.5V to V
O
+1.5V
Load Regulation LDR I
O
= 1mA to 1.5A 0.5 1 %
Over Temperature Shutdown OTS 160 °C
Over Temperature Hysteresis OTH 30 °C
Temperature Coefficient T
C
40 ppm/°C
Power Supply Ripple Rejection PSRR I
O
= 100mA
f = 100Hz 55
dB f = 1kHz 50
f = 10kHz 35
