PAM3110
Document number: DSxxxxx Rev. 2 - 2
3 of 13
www.diodes.com
September 2013
© Diodes Incorporated
PAM3110
A Product Line of
Diodes Incorporated
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
These are stress ratings only and functional operation is not implied. Exposure to absolute maximum ratings for prolonged time periods may
affect device reliability. All voltages are with respect to ground.
Parameter Rating Unit
Input Voltage 6 V
Storage Temperature -65 to +150 °C
Maximum Junction Temperature 150 °C
Lead Soldering Temperature 300, (5sec) °C
Recommended Operating Conditions
(@T
A
= +25°C, unless otherwise specified.)
Parameter Rating Unit
Supply Voltage 2.5 to 5.5 V
Ambient Temperature Range -40 to +85
°C
Junction Temperature Range -40 to +125
Thermal Information
Parameter Symbol Package Max Unit
Thermal Resistance Junction to Case) θ
JC
SOT-223 7
°C/W
TO-252 7
TO-263 7
Thermal Resistance (Junction to Ambient) θ
JA
SOT-223 160
TO-252 90
TO-263 60
Internal Power Dissipation (@T
A
= 25°C) P
D
SOT-223 625
mW TO-252 1200
TO-263 2000
