LM4040
PRECISION MICROPOWER SHUNT VOLTAGE REFERENCES
LM4040
Document number: DS33195 Rev. 5 - 2
3 of 12
March 2012
© Diodes Incorporated
A Product Line of
Diodes Incorporated
Electrical Characteristics
(Test conditions: T
AMB
= 25°C, unless otherwise specified.)
LM4040-2.5
Symbol
Parameter
Conditions
Typ.
LM4040
B Limits
LM4040
C Limits
LM4040
D Limits
Units
T
AMB
V
REF
Reverse breakdown
voltage
I
R
= 100µA
25°C 2.5
V
Reverse breakdown
voltage tolerance
I
R
= 100µA
25°C
±5 ±12 ±25
mV
-40 to +85°C
±21
±29
±49
-40 to +125°C
±30
±38
±63
I
RMIN
Minimum operating
current
25°C 45
60 60
65
µA
-40 to +85°C
65 65 70
-40 to +125°C
68
68
73
ΔV
R
/
ΔT
Average reverse
breakdown voltage
temperature coefficient
I
R
= 10mA
-40 to +125°C
±20
I
R
= 1mA
±15 ±100 ±100
±150 ppm/°C
I
R
= 100µA
±15
ΔV
R
/
ΔI
R
Reverse breakdown
change with current
I
RMIN
I
R
< 1mA
25°C 0.3 0.8 0.8 1.0
mV
-40 to +85°C
1.0 1.0 1.2
-40 to +125°C
1.0
1.0
1.2
1mA < I
R
< 15mA
25°C 2.5 6.0 6.0 8.0
-40 to +85°C
8.0 8.0 10.0
-40 to +125°C
8.0
8.0
10.0
Z
R
Dynamic output
impedance
I
R
= 1mA, f = 120Hz
I
AC
= 0.1I
R
0.3 0.8
0.9
1.1
Ω
e
n
Noise voltage
I
R
= 100µA
10Hz < f < 10kHz
35
µV
RMS
V
R
Long term stability (non
cumulative)
t = 1000Hrs, I
R
= 100µA
120
ppm
V
HYST
Themal hysteresis
ΔT = -40°C to =125°C
0.08
%
