LM4040
PRECISION MICROPOWER SHUNT VOLTAGE REFERENCES
LM4040
Document number: DS33195 Rev. 5 - 2
2 of 12
www.diodes.com
March 2012
© Diodes Incorporated
A Product Line of
Diodes Incorporated
Absolute Maximum Ratings
(Voltages to GND Unless Otherwise Stated)
Parameter Rating Unit
Continuous Reverse Current 20 mA
Continuous Forward Current 10 mA
Operating Junction Temperature -40 to +150 °C
Storage Temperature -55 to +150 °C
Operation above the absolute maximum rating may cause device failure. Operation at the absolute maximum rating,
for extended periods, may reduce device reliability.
Unless otherwise stated voltages specified are relative to the ANODE pin.
Package Thermal Data
Package θ
JA
P
DIS
T
AMB
= 25°C, T
J
= 150°C
SOT23 380°C/W 330mW
SC70-5 380°C/W 330mW
Recommended Operating Conditions
Min. Max. Units
Reverse Current 0.06 15 mA
Operating Ambient Temperature Range -40 125 °C
