DMC1229UFDB

Document number: DS36128 Rev. 4 - 2

2 of 9

www.diodes.com

September 2013

© Diodes Incorporated

DMC1229UFDB




Maximum Ratings

(@T

A

= +25°C, unless otherwise specified.)

Characteristic Symbol

Q1

N-CHANNEL

Q2

P-CHANNEL

Units

Drain-Source Voltage

V

DSS

12 -12

V

Gate-Source Voltage

V

GSS

±8 ±8

V

Continuous Drain Current (Note 5) V

GS

= 4.5V

Steady

State

T

A

= +25

C

T

A

= +70

C

I

D

5.6
4.4

-3.8
-3.0

A

t < 5s

T

A

= +25

C

T

A

= +70

C

I

D

7.2
5.8

-5.0
-4.0

A

Maximum Continuous Body Diode Forward Current (Note 5)

I

S

1

-1

A

Pulsed Drain Current (10

s pulse, duty cycle = 1%)

I

DM

20 -15

A



Thermal Characteristics

Characteristic Symbol

Value

Units

Total Power Dissipation (Note 5)

Steady State

P

D

1.4

W

t < 5s

2.2

Thermal Resistance, Junction to Ambient (Note 5)

Steady State

R

JA

92

°C/W

t < 5s

55

Thermal Resistance, Junction to Case (Note 5)

R

JC

30

Operating and Storage Temperature Range

T

J,

T

STG

-55 to 150

°C

Note:

5. Device mounted on 1” x 1” FR-4 PCB with high coverage 2oz. Copper, single sided.
