DMN2300UFL4
Datasheet Number: DS35946 Rev. 1 - 2
2 of 7
May 2012
© Diodes Incorporated
DMN2300UFL4
A Product Line of
Diodes Incorporated
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Drain-Source Voltage
V
DSS
20 V
Gate-Source Voltage
V
GSS
±8 V
Continuous Drain Current (Note 6)
Steady
State
T
A
= 25°C
T
A
= 85°C
I
D
2.11
1.19
A
Pulsed Drain Current (Note 7)
I
DM
6.0 A
Thermal Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Value
Unit
Power Dissipation
(Note 5)
P
D
0.53
W
(Note 6)
1.39
Thermal Resistance, Junction to Ambient
(Note 5)
R
θJA
238
°C/W
(Note 6)
90
Operating and Storage Temperature Range
T
J
,
T
STG
-55 to +150
°C
Notes:
5. Device mounted on FR-4 substrate PC board, 2oz copper, with minimum recommended pad layout;
6. Device mounted on FR-4 substrate PC board, 2oz copper, with 1inch square copper plate
7. Device mounted on minimum recommended pad layout test board, 10
μs pulse duty cycle = 1%.
0.0001 0.001
0.01
0.1
1
10
100
t1, PULSE DURATION TIME (sec)
Fig. 1 Single Pulse Maximum Power Dissipation
0
10
20
30
40
50
60
70
80
90
100
P
,
P
EA
K
T
R
ANSI
EN
T
P
O
IW
E
R
(W
)
(P
K
)
Single Pulse
R
= 230 C/W
R
= r
* R
T - T = P * R
θ
θ
θ
θ
JA
JA(t)
(t)
JA
J
A
JA(t)
°
0.00001
0.0001
0.001
0.01
0.1
1
10
100
1,000
t1, PULSE DURATION TIMES (sec)
Fig. 2 Transient Thermal Resistance
0.001
0.01
0.1
r(t
),
T
R
ANS
IEN
T
T
H
E
R
MA
L
R
ES
IS
T
AN
C
E
1
R
(t) = r(t) * R
R
= 230°C/W
Duty Cycle, D = t1/ t2
θ
θ
θ
JA
JA
JA
D = 0.7
D = 0.9
D = 0.5
D = 0.3
D = 0.1
D = 0.05
D = 0.02
D = 0.01
D = 0.005
Single Pulse
