DMN1019UFDE

D

atasheet number: DS35561 Rev. 5 - 2

1 of 7

www.diodes.com

October 2013

© Diodes Incorporated

DMN1019UFDE

ADVAN

CE I

N

F

O

RM

ATI

O

N

12V N-CHANNEL ENHANCEMENT MODE MOSFET

Product Summary

V

(BR)DSS

R

DS(ON) max

Package

I

D max

T

A

= +25°C

12V

10mΩ @ V

GS

= 4.5V

U-DFN2020-6

Type E

11A

12mΩ @ V

GS

= 2.5V

10

14mΩ @ V

GS

= 1.8V

9A

18mΩ @ V

GS

= 1.5V

8A

41mΩ @ V

GS

= 1.2V

5A

Description

This new generation MOSFET has been designed to minimize the on-
state resistance (RDS(on)) and yet maintain superior switching
performance, making it ideal for high efficiency power management
applications.

Applications

Load Switching

Battery Management Application

Power Management Functions


Features

0.6mm profile – ideal for low profile applications

PCB footprint of 4mm2

Low Gate Threshold Voltage

Fast Switching Speed

 ESD

Protected

Gate

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Qualified to AEC-Q101 Standards for High Reliability


Mechanical Data

Case: U-DFN2020-6 Type E

Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminals: Finish – NiPdAu over Copper leadframe. Solderable
per MIL-STD-202, Method 208

Weight: 0.008 grams (approximate)















Ordering Information

(Note 4)

Part Number

Marking

Reel size (inches)

Quantity per reel

DMN1019UFDE-7 N7

7

3,000

Notes:

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"

and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

4. For packaging details, go to our website at http://www.diodes.com/products/packages.html

Marking Information










Date Code Key

Year

2011

2012

2013

2014

2015

2016

2017

Code Y Z A B C D E

Month

Jan

Feb

Mar

Apr

May

Jun

Jul

Aug

Sep

Oct

Nov

Dec

Code 1 2 3 4 5 6 7 8 9 O N D

Bottom View

ESD PROTECTED

N7 = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: A = 2013)
M = Month (ex: 9 = September)

N7

YM

Equivalent Circuit

U-DFN2020-6

Type E

Pin Out

Bottom View

Pin1

e4

D

S

G

Gate Protection

Diode
