Diodes DMG8601UFG - Manual (Page 5)

DMG8601UFG
Document number: DS31788 Rev. 5 - 2
5 of 6
www.diodes.com
September 2012
© Diodes Incorporated
DMG8601UFG
NEW PROD
UC
T
0.00001 0.0001 0.001 0.01 0.1 1 10 100 1,000
Fig. 12 Transient Thermal Response
t , PULSE DURATION TIME (s)
1
0.001
0.01
0.1
1
r(
t),
T
R
AN
S
IE
N
T
T
H
E
R
MA
L
R
ES
IS
T
AN
C
E
T - T = P * R (t)
Duty Cycle, D = t /t
J A JA
1 2
θ
R (t) = r(t) * θJA R
R = 136°C/W
θ
θ
JA
JA
P(pk)
t
1
t
2
D = 0.7
D = 0.3
D = 0.1
D = 0.05
D = 0.02
D = 0.01
D = 0.005
D = Single Pulse
D = 0.9
D = 0.5
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
Suggested Pad Layout
Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.
U-DFN3030-8
Dim Min Max Typ
A 0.57 0.63 0.60
A1 0 0.05 0.02
A3 ⎯ ⎯ 0.15
b 0.29 0.39 0.34
D 2.90 3.10 3.00
D2 2.19 2.39 2.29
e ⎯ ⎯ 0.65
E 2.90 3.10 3.00
E2 1.64 1.84 1.74
L 0.30 0.60 0.45
All Dimensions in mm
Dimensions Value (in mm)
Z 2.59
G 0.11
X1 2.49
X2 0.65
Y 0.39
C 0.65
D
A1
A
A3
E2
D2
L
E
SEATING PLANE
e b
R0
.20
0
Z
G
X1
X2
Y C
