Package outline dimensions, Suggested pad layout – Diodes HBDM60V600W User Manual
Page 7
HBDM60V600W
Document number: DS30701 Rev
.com
July 2008
© Diodes Incorporated
Package Outline Dimensions
HBDM60V600W
Suggested Pad Layout
. 5 - 2
7 of 7
IMPORTANT NOTICE
Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes
without further notice to any product herein. Diodes Incorporated does not assume any liability arising out of the application or use of any product
described herein;
ghts of others. The user of products in such applications shall
neither does it convey any license under its patent rights, nor the ri
assume all risks of such
rporated a
are represented on our website,
use and will agree to hold Diodes Inco
nd all the companies whose products
harmless against all damages.
LIFE SUPPORT
Diodes Incorporated pro
al compo
ystems without the expressed written
ducts are not authorized for use as critic
nents in life support devices or s
approval of the President of Diodes Incorporated.
SOT-363
Dim
Min
Max
A
0.10
0.30
B
1.15
1.35
C
2.00
2.20
D
0.65 Typ
F
0.40
0.45
H
1.80
2.20
J
0
0.10
K
0.90
1.00
L
0.25
0.40
M
0.10
0.22
α
0° 8°
All Dimensions in mm
Dimensions
Value (in mm)
Z
2.5
G
1.3
X
0.42
Y
0.6
C
1.9
E
0.65
A
M
J
L
D
B C
H
K
F
E
E
X
Z
Y
C
G
