DSS60601MZ4
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Collector-Base Voltage V
CBO
100 V
Collector-Emitter Voltage V
CEO
60 V
Emitter-Base Voltage V
EBO
6 V
Continuous Collector Current I
C
6 A
Peak Pulse Collector Current I
CM
12 A
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation
(Note 5)
P
D
3
W (Note 6) 2
(Note 7) 1.2
Thermal Resistance, Junction to Ambient
(Note 5)
R
θJA
41.7
C/W (Note 6) 62.5
(Note 7) 104
Thermal Resistance, Junction to Leads (Note 8) R
θJL
12.9 C/W
Operating and Storage Temperature Range T
J,
T
STG
-55 to +150 C
ESD Ratings
(Note 9)
Characteristic Symbol Value Unit JEDEC Class
Electrostatic Discharge - Human Body Model ESD HBM 4,000 V 3A
Electrostatic Discharge - Machine Model ESD MM 400 V C
Notes: 5. For a device mounted with the collector lead on 50mm x 50mm 2oz copper that is on a single-sided 1.6mm FR4 PCB; device is measured under still air
conditions whilst operating in steady-state.
6. Same as note (5), except the device is mounted on 25mm x 25mm 2oz copper.
7. Same as note (5), except the device is mounted on minimum recommended pad (MRP) layout.
8. Thermal resistance from junction to solder-point (at the end of the collector lead).
9. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
