DSS4160DS
Document number DS36556 Rev. 1 – 2
2 of 7
www.diodes.com
November 2013
© Diodes Incorporated
DSS4160DS
Absolute Maximum Ratings – Q1 & Q2 Common
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Collector-Base Voltage V
CBO
80 V
Collector-Emitter Voltage V
CEO
60 V
Emitter-Base Voltage V
EBO
5 V
Continuous Collector Current I
C
1 A
Peak Pulse Collector Current I
CM
2 A
Base current I
B
300 mA
Peak Pulse Base current I
BM
1 A
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation
Linear Derating Factor
(Notes 5 & 9)
P
D
0.7
5.6
W
mW/ C
(Notes 6 & 9)
0.9
7.2
(Notes 6 & 10)
1.1
8.8
(Notes 7 & 9)
1.1
8.8
(Notes 8 & 9)
1.7
13.6
Thermal Resistance, Junction to Ambient
(Notes 5 & 9)
R
JA
179
C/W
(Notes 6 & 9) 139
(Notes 6 & 10) 113
(Notes 7 & 9) 113
(Notes 8 & 9) 73
Thermal Resistance, Junction to Lead (Note 11) R
JL
96
Operating and Storage Temperature Range T
J
, T
STG
-55 to +150 C
ESD Ratings
(Note 12)
Characteristic Symbol Value Unit JEDEC Class
Electrostatic Discharge - Human Body Model ESD HBM 4,000 V 3A
Electrostatic Discharge - Machine Model ESD MM 400 V C
Notes: 5. For a device mounted with the collector lead on 15mm x 15mm 1oz copper that is on a single-sided 1.6mm FR4 PCB; device is measured under still air
conditions whilst operating in a steady-state.
6. Same as note (5), except the device is mounted on 25mm x 25mm 1oz copper.
7. Same as note (5), except the device is mounted on 50mm x 50mm 2oz copper.
8. Same as note (7), except the device is measured at t < 5 seconds.
9. One active die operating with the collector attached to the heatsink.
10. Two active dice running at equal power with heatsink split 50% to each collector.
11. Thermal resistance from junction to solder-point (at the end of the collector lead).
12. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
