74LVC1G34
Switching Characteristics
(Typical Values @ T
A
= +25°C and nominal voltages 1.8V, 2.5V, 2.7V, 3.3V, and 5.0V)
Parameter
From
Input To
Output
V
CC
T
A
= -40°C to +85°C T
A
= -40°C to +125°C
Unit
Min Typ Max Min Max
t
pd
A or B Y
1.8V ± 0.15V 1.0 3.0 7.5 1.0 9.5
ns
2.5V ± 0.2V 0.5 2.0 5.0 0.5 6.5
2.7V 0.5 2.3 5.2 0.5 7.0
3.3V ± 0.3V 0.5 2.0 4.2 0.5 5.5
5.0V ± 0.5V 0.5 1.6 3.7 0.5 5.0
Operating Characteristics
(T
A
= +25°C, unless otherwise specified.)
Parameter
Test
Conditions
V
CC
= 1.8V V
CC
= 2.5V V
CC
= 3.3V V
CC
= 5V
Unit
Typ Typ Typ Typ
C
pd
Power Dissipation
Capacitance
f = 10 MHz 16 16 16 16 pF
