74AUP2G17
NEW PROD
UC
T
Operating and Package Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Parameter
Test
Conditions
V
CC
Typ Unit
C
pd
Power Dissipation
Capacitance f = 1MHz
No Load
0.8V 5.1
pF
1.2V ± 0.1V 5.2
1.5V ± 0.1V 5.2
1.8V ± 0.15V 5.5
2.5V ± 0.2V 5.7
3.3V ± 0.3V 6.0
C
I
Input Capacitance V
i
= V
CC
or GND 0V or 3.3V 2.0 pF
C
O
Output Capacitance V
O
= V
CC
or GND 0V 2.0 pF
Parameter Measurement Information
R
L
C
L
(see Note A)
From Output
Under Test
=1M Ω
Vcc
Inputs
V
M
C
L
V
I
t
r
/t
f
1.2V ± 0.1V V
CC
≤3ns V
CC
/2 5, 10, 15, 30pF
1.5V ± 0.1V V
CC
≤3ns V
CC
/2 5, 10, 15, 30pF
1.8V ± 0.15V V
CC
≤3ns V
CC
/2 5, 10, 15, 30pF
2.5V ± 0.2V V
CC
≤3ns V
CC
/2 5, 10, 15, 30pF
3.3V ± 0.3V V
CC
≤3ns V
CC
/2 5, 10, 15, 30pF
0V or 3.3V V
CC
≤3ns V
CC
/2 5, 10, 15, 30pF
Voltage Waveform Pulse Duration
Voltage Waveform Propagation Delay Times
Inverting and Non Inverting Outputs
Figure 1 Load Circuit and Voltage Waveforms
Notes: A. Includes test lead and test apparatus capacitance.
B. All pulses are supplied at pulse repetition rate ≤ 10MHz.
C. Inputs are measured separately one transition per measurement.
D. t
PLH
and t
PHL
are the same as t
PD.
