Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter Test Conditions V
CC
T
A
= +25°C T
A
= -40°C to +85°C Unit
Min Max Min Max
V
T+
Positive-going Input
Threshold Voltage
0.8V 0.3 0.6 0.3 0.6
V
1.1V 0.53 0.9 0.53 0.9
1.4V 0.74 1.11 0.74 1.11
1.65V 0.91 1.29 0.91 1.29
2.3V 1.37 1.77 1.37 1.77
3.0V 1.88 2.29 1.88 2.29
V
T-
Negative-going Input
Threshold Voltage
0.8V 0.1 0.6 0.1 0.6
V
1.1V 0.26 0.65 0.26 0.65
1.4V 0.39 0.75 0.39 0.75
1.65V 0.47 0.84 0.47 0.84
2.3V 0.69 1.04 0.69 1.04
3.0V 0.88 1.24 0.88 1.24
∆V
T
Hysteresis
(V
T+
- V
T-)
0.8V 0.07 0.5 0.07 0.5
V
1.1V 0.08 0.46 0.08 0.46
1.4V 0.18 0.56 0.18 0.56
1.65V 0.27 0.66 0.27 0.66
2.3V 0.53 0.92 0.53 0.92
3.0V 0.79 1.31 0.79 1.31
V
OH
High-Level Output
Voltage
I
OH
= -20μA 0.8V to 3.6V V
CC
– 0.1 V
CC
– 0.1
V
I
OH
= -1.1mA 1.1V 0.75 X V
CC
0.7 X V
CC
I
OH
= -1.7mA 1.4V 1.11 1.03
I
OH
= -1.9mA 1.65V 1.32 1.30
I
OH
= -2.3mA
2.3V
2.05 1.97
I
OH
= -3.1mA 1.9 1.85
I
OH
= -2.7mA
3V
2.72 2.67
I
OH
= -4mA 2.6 2.55
V
OL
Low-Level Output
Voltage
I
OL
= 20μA 0.8V to 3.6V 0.1 0.1
V
I
OL
= 1.1mA 1.1V 0.3 X V
CC
0.3 X V
CC
I
OL
= 1.7mA 1.4V 0.31 0.37
I
OL
= 1.9mA 1.65V 0.31 0.35
I
OL
= 2.3mA
2.3V
0.31 0.33
I
OL
= 3.1mA 0.44 0.45
I
OL
= 2.7mA
3V
0.31 0.33
I
OL
= 4mA 0.44 0.45
I
I
Input Current V
I
= GND to 3.6V 0 to 3.6V ± 0.1 ±0.5 μA
I
OFF
Power Down Leakage
Current
V
I
or V
O
= 0V to 3.6V 0V ± 0.2 ±0.5 μA
∆I
OFF
Delta Power Down
Leakage Current
V
I
or V
O
= 0V to 3.6V 0V to 0.2V ± 0.2 ±0.6 μA
I
CC
Supply Current V
I
= GND or V
CC
, I
O
= 0 0.8V to 3.6V 0.5 0.9 μA
∆I
CC
Additional Supply
Current
Input at V
CC
-0.6V 3.3V 40 50 μA
