Dual 4-channel Analog Multiplexer/Demultiplexer AZ4052
Oct. 2011 Rev. 1. 1 BCD Semiconductor Manufacturing Limited
14
Typical Performance Characteristics (Continued)
Figure 25. Waveforms Showing the Turn-on and Turn-off Times
(V
M
= 50 %, V
I
= GND to V
CC
)
Figure 26. Input Pulse Definitions
t
r
and t
f
Amplitude V
M
F
max
Pulse
Width
Other
V
CC
50% < 2ns 6ns
