Data Sheet
Enhanced Multi-touch Capacitive Touch Screen Controller CS5519
Apr. 2013 Rev. 1. 0 BCD Semiconductor Manufacturing Limited
8
CS5519 Support 7” to 13” Touch Panel, Listed Below:
PN
TX/ RX
Multi - Touch
Package
Panel size
CS5519
30/17
10 point 100HZ
QFN-7x7-56
7” to 10”
38/22
10 point 100HZ
QFN-8x8-68
8” to 13”
Absolute Maximum Ratings (Note 1)
Parameter
Symbol Value
Unit
Supply Voltage 1
V
DD
2.8 to 3.6
V
Supply Voltage 2
V
DD18
1.6 to 2.0
V
Analog Input Voltage (Other pins)
V
DDA
-0.3
to
V
DD
+0.3 V
Logic Input Voltage
V
DDD
-0.3
to
V
DD
+0.3 V
Power Dissipation
P
D
250 mW
Maximum Junction Temperature
T
J
100 °C
Operating Temperature
T
OP
-40
to
95
°C
Storage Temperature
T
STG
-65
to
150
°C
Note 1: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under “Recommended Operating Conditions” is not implied. Exposure to “Absolute
Maximum Ratings” for extended periods may affect device reliability.
