Data Sheet

Enhanced Multi-touch Capacitive Touch Screen Controller CS5519

Apr. 2013 Rev. 1. 0 BCD Semiconductor Manufacturing Limited

15

Mounting Pad Layout

QFN-7×7-56

X

Y

Y2

E

E

X2

X1

Y1

Y3

X3

Dimensions

X=Y

(mm)/(inch)

X1=Y1

(mm)/(inch)

X2=Y2

(mm)/(inch)

X3=Y3

(mm)/(inch)

E

(mm)/(inch)

Value

7.400/0.291 5.400/0.213 0.250/0.010 0.700/0.028 0.400/0.016
