APX803/D
3-PIN MICROPROCESSOR RESET CIRCUIT
APX803
Document number: DS32132 Rev. 2 - 2
8 of 11
www.diodes.com
September 2010
© Diodes Incorporated
Ordering Information
APX 8 03 - XX XX G - 7
Voltage Package Packing
7 : Tape & Reel
Output type Green
G : Green SA : SOT23 46 : 4.63
44 : 4.38
40 : 4.00
31 : 3.08
29 : 2.93
26 : 2.63
23 : 2.25
03 : Active-Low,
Open Drain
SR : SOT23R
APX 8 03 D - 29 XX G - 7
Voltage Package Packing
7 : Tape & Reel
Output type Green
G : Green SA : SOT23 03 : Active-Low,
Open Drain
SR : SOT23R
29 : 2.93
Device Package Code
Packaging
(Note 4)
7” Tape and Reel
Quantity Part Number Suffix
APX803-XXSAG-7 SA SOT23 3000/Tape & Reel -7
APX803-XXSRG-7 SR SOT23R 3000/Tape & Reel -7
APX803D-29SAG-7 SA SOT23 3000/Tape & Reel -7
APX803D-29SRG-7 SR SOT23R 3000/Tape & Reel -7
Notes: 4. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
http://www.diodes.com/datasheets/ap02001.pdf.
