Diodes APX803/D - Manual (Page 3)

APX803/D
3-PIN MICROPROCESSOR RESET CIRCUIT
APX803
Document number: DS32132 Rev. 2 - 2
3 of 11
www.diodes.com
September 2010
© Diodes Incorporated
Absolute Maximum Ratings
Symbol Parameter Rating Unit
ESD HBM Human Body Model ESD Protection 2 kV
ESD MM Machine Model ESD Protection 200 V
V
CC
Supply Voltage -0.3 to +6.0 V
V
RESET RESET (open drain) -0.3 to 6 V
I
CC
Input Current, V
CC
20 mA
I
O Output Current, RESET 20 mA
P
D
Continuous Power Dissipation (T
A
= +70°C), de-
rate 4mW/°C above +70°C
400 mW
T
OP
Operating Junction Temperature Range -40 to +105 °C
T
ST
Storage Temperature Range -65 to +150 °C
Recommended Operating Conditions
Symbol Parameter Min Max Unit
V
CC
Supply Voltage 1.1 5.5 V
V
IN
Input Voltage 0 (V
CC
+0.3) V
V
RESET RESET output voltage 0 5.5 V
T
A
Operating Ambient Temperature Range -40 85 °C
dV
CC
/dt V
CC
Rate of rise (V
CC
= 0~V
T
) 100 V/µs
