Page 6
AH182/AH183
LOW POWER HALL EFFECT SWITCH
AH182/AH183 Rev. 8
6 of 10
NOVEMBER 2009
DS31024
©
Diodes Incorporated
Performance Characteristics
(1) SIP-3L
T
A
(
°C)
25
50
60
70
80
85
90
95
100
P
D
(mW)
550 440 396 352 308 286 264 242 220
T
A
(
°C)
105
110
115
120
125
130
135
140
150
P
D
(mW) 198
176
154
132
110
88
66
44
0
Power Dissipation Curve
0
1 00
2 00
3 00
4 00
5 00
6 00
0
25
50
75
100
1 25
15 0
T
A
(
o
C)
P
D
(mW )
85
-40
(2) SC59 (Commonly known as SOT23 in Asia)
T
A
(
°C)
25
50
60
70
80
85
90
100
110
120
130
140
150
P
D
(mW)
230 184 166 147 129 120 110 92 74 55 37 18 0
P o w e r D is s i p a tio n C u rv e
0
1 0 0
2 0 0
3 0 0
0
2 5
5 0
7 5
1 0 0
1 2 5
1 5 0
T
A
(
o
C )
P
D
(m W )
8 5
-4 0
