AH182/AH183
LOW POWER HALL EFFECT SWITCH
AH182/AH183 Rev. 8
2 of 10
NOVEMBER 2009
DS31024
©
Diodes Incorporated
AH182 / AH183 - X X - X
Packing
W : SC59
Package
Lead Free
L : Lead Free
CMOS Hall-effect Switch
B : Bulk (Note 4)
7 : Tape & Reel
A : Ammo Box (Note 3)
P : SIP-3L
G : Green
Device
Package
Code
Packaging
(Note 2)
Bulk
7” Tape and Reel
Ammo Box
Quantity
Part
Number
Suffix
Quantity
Part
Number
Suffix
Quantity
Part
Number
Suffix
AH182/AH183-PL-A
P
SIP-3L
NA
NA NA NA
4000/Box
-A
AH182/AH183-PL-B P SIP-3L
1000 -B
NA
NA NA NA
AH182/AH183-PG-A
P
SIP-3L
NA
NA NA NA
4000/Box
-A
AH182/AH183-PG-B P SIP-3L 1000 -B
NA
NA NA
NA
AH182/AH183-WL-7 W SC59 NA NA
3000/Tape
&
Reel
-7
NA
NA
AH182/AH183-WG-7 W SC59 NA NA
3000/Tape
&
Reel
-7
NA
NA
Notes: 1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
2. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
3. Ammo Box is for SIP-3L Spread Lead.
4. Bulk is for SIP-3L Straight Lead.
(1) SIP-3L
(2) SC59 (Commonly known as SOT23 in Asia)
1. Vdd
2. GND
3.
(Top view)
Output
1. Vdd
GND 2.
3. Output
(Top view)
Ordering Information
Pin Assignments
Pin Description
Pin Name
P/I/O
Pin #
Description
Vdd
P/I 1
Power Supply Input
GND
P 2
Ground
Output O 3
Output
Pin
