Package Outline Dimensions (All dimensions in mm.)
(2) Package type: SOT89-5L
1.24/1.4
4
0.73/0.8
7
SOT89-5
Dim Min Max Typ
A 1.40 1.60 1.50
B 0.50 0.62 0.56
B1 0.44 0.54 0.48
C 0.35 0.43 0.38
D 4.40 4.60 4.50
D1 1.62 1.83 1.733
E 2.40 2.60 2.50
e — — 1.50
H 3.95 4.25 4.10
L 0.65 0.95 0.80
All Dimensions in mm
E
H
D 1
B 1
B
e
C
L
A
D
8 ° ︵4 x
︶
R0
.2
00
L
