AH2984
Functional Block Diagram
(1) For SIP-4
Hall
Plate
Control Logic
Regulator
Lock detect,
Shutdown and
Automatic re-start
Vdd
DOB
DO
Amp.
1
2
3
4
GND
(2) For SOT89-5
Hall
Plate
Control Logic
Regulator
Vdd
DOB
DO
Amp.
1
3
4
2
GND
NC 5
Lock detect,
Shutdown and
Automatic re-start
