AP8802

1A LED STEP-DOWN CONVERTER

AP8802

Document number: DS31766 Rev. 9 - 2

18 of 19

www.diodes.com

May 2012

© Diodes Incorporated

Suggested Pad Layout


(1) Package Type: SO-8



















(2) Package Type: SO-8EP



















(3) Package Type: U-DFN3030-10














Dimensions

Value (in mm)

X

0.60

Y

1.55

C1

5.4

C2

1.27

Dimensions

Value

(in mm)

C

1.270

X

0.802

X1

3.502

X2

4.612

Y

1.505

Y1

2.613

Y2

6.500

Dimensions Value (in mm)

Z

2.60

G

0.15

X

1.80

X1

0.60

Y

0.30

C

0.50

X

C1

C2

Y

C

Y

Z

X

X1

G

G

C

Y 1

X 1

X

Y

Y 2

X 2
