AL5812

Document number: DS35616 Rev. 2 - 2

10 of 11

www.diodes.com

November 2013

© Diodes Incorporated

NEW PROD

UC

T

AL5812

Suggested Pad Layout

Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for latest version.

(1) MSOP-8EP

(2) U-DFN3030-6

Dimensions

Value

(in mm)

C

0.650

G

0.450

X

0.450

X1

2.000

Y

1.350

Y1

1.700

Y2

5.300

Dimensions

Value

(in mm)

C

0.950

X

0.500

X1

2.400

X2

2.550

Y

0.600

Y1

1.780

Y2

3.300

G

X

C

Y

Y2

Y1

X1

X 2

Y 1

Y

C

Y 2

X 1

X

C - 0 . 4 0 9
