Diodes AL5812 User Manual
Al5812, New prod uc t al5812, Description

AL5812
Document number: DS35616 Rev. 2 - 2
1 of 11
November 2013
© Diodes Incorporated
NEW PROD
UC
T
AL5812
60V, 150mA ADJUSTABLE LINEAR LED DRIVER
Description
The AL5812 is an adjustable Linear LED driver offering excellent
temperature stability and output handling capability. The AL5812
simplifies the design of linear and isolated or non-isolated LED drivers
by setting the LED current with standard value resistors.
The AL5812 has an open drain output that can swing from 1V up to
60V enabling it drive long LED chains. Its low 0.5V R
SET
pin is outside
of the LED current path and so accuracy is maintained while
minimizing the required overheads to regulate the LED current. This
reduces its power dissipation when compared to traditional linear LED
drivers. This makes it ideal for driving LEDs up to 150mA (commonly
referred to as ½W LEDs).
Longer LED chains can be driven by tapping V
CC
from the chain,
where the chain voltage may exceed 60V.
The AL5812 is available in the exposed pad MSOP-8EP and
U-DFN3030-6 packages.
Features
•
Low Reference Voltage (V
RSET
= 0.5V)
•
-40°C to +125°C Temperature Range
•
±3% LED Current Tolerance
•
Low Temperature Drift
•
1V to 60V Open-Drain Output
•
High Power Supply Rejection
•
MSOP-8EP and U-DFN3030-6
•
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
•
Halogen and Antimony Free. “Green” Device (Note 3)
Pin Assignments
LED
NC
NC
GND
R
SET
NC
NC
V
CC
1
2
3
4
8
7
6
5
(Top View)
MSOP-8EP
U-DFN3030-6
(Top View)
LED
NC
GND
V
CC
NC
R
SET
3
2
1
4
5
6
Exposed
Pad
Applications
•
Isolated Offline LED Converters
•
Linear LED Driver
• LED
Signs
• Instrumentation
Illumination
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. S
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
Typical Applications Circuit
AL5812
LED
GND
V
CC
R
SET
R
7k5
SET
V
IN
C 0.1µF
IN
