500mA LOW NOISE LDO REGULATOR AP2213
Data Sheet
8
Dec. 2012 Rev. 2. 0 BCD Semiconductor Manufacturing Limited
V
IN
=4V, I
OUT
=100 μA, C
IN
=1.0 μF, C
OUT
=2.2 μF, V
EN
≥2.0V, T
J
=25 o C, Bold typeface applies over -40 o C ≤T
J
≤125 o C (Note 2),
unless otherwise specified.
AP2213-3.0 Electrical Characteristics
Electrical Characteristics (Continued)
Parameter Symbol Conditions Min Typ Max Unit
Output Voltage Accuracy ΔV
OUT
/V
OUT
Variation from specified
V
OUT
-1 1
%
-2 2
Output Voltage
Temperature Coefficient
(Note 3) ΔV
OUT
/ ΔT 120 μV/ o C
( ΔV
OUT
/V
OUT
)/ ΔT 40
ppm/ o C
Line Regulation V
RLINE
V
IN
=4V to 13.2V
1.5 4.5
mV
12
Load Regulation
(Note 4)
V
RLOAD
I
OUT
=0.1mA to 500mA
1 8
mV
17
Dropout Voltage (Note 5) V
DROP
I
OUT
=100 μA
15 50
mV
70
I
OUT
=50mA
110 150
230
I
OUT
=100mA
140 250
300
I
OUT
=150mA
165 275
350
I
OUT
=300mA
250 400
500
I
OUT
=500mA
350 600
700
Standby Current I
STD
V
EN
≤0.4V (shutdown) 0.01 1
μA
V
EN
≤0.18V (shutdown) 5
Ground Pin Current
(Note 6)
I
GND
V
EN
≥2.0V, I
OUT
=100 μA
100 150
μA
180
V
EN
≥2.0V, I
OUT
=50mA
350 600
800
V
EN
≥2.0V, I
OUT
=150mA
1.3 1.9
mA
2.5
V
EN
≥2.0V, I
OUT
=300mA
4 10
15
V
EN
≥2.0V, I
OUT
=500mA
11 20
28
