500mA LOW NOISE LDO REGULATOR AP2213
Data Sheet
2
Dec. 2012 Rev. 2. 0 BCD Semiconductor Manufacturing Limited
Pin Number
Pin Name Function
TO-252-2 (1)/
TO-252-2 (3)
SOIC-8 SOT-223
3 3 2 VOUT Regulated output voltage
2 5, 6, 7, 8 1 GND Ground
1 2 3 VIN Input Voltage
1 EN
Enable input: CMOS or TTL compatible input. Logic
high=enable, logic low=shutdown
4 BYP Bypass capacitor for low noise operation
Figure 2. Pin Configuration of AP2213 (Top View)
Pin Configuration
M Package
(SOIC-8)
D Package
(TO-252-2 (1))
H Package
(SOT-223)
VOUT
GND
VIN 1
2
3
1
2
3
4
8
7
6
5
VOUT
GND
VIN GND
GND
GND BYP
EN VIN
VOUT
GND 1
2
3
(TO-252-2 (3))
Pin Description
1
2
3
VIN
VOUT
GND
