500mA LOW NOISE LDO REGULATOR AP2213
Data Sheet
5
Dec. 2012 Rev. 2. 0
BCD Semiconductor Manufacturing Limited
Parameter
Symbol
Value
Unit
Supply Input Voltage
V
IN
20
V
Enable Input Voltage
V
EN
20
V
Power Dissipation
P
D
Internally Limited (Thermal Protection)
W
Lead Temperature (Soldering, 10sec)
T
LEAD
260
o
C
Junction Temperature
T
J
150
o
C
Storage Temperature
T
STG
-65 to 150
o
C
ESD (Machine Model)
ESD
300
V
Thermal Resistance (No Heatsink)
θ
JA
TO-252-2
(1)/TO-252-2
(
3)
90
o
C/W
SOIC-8
160
SOT-223
108
Note 1: Stresses greater than those listed under "Absolute Maximum Ratings" may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under "Recommended Operating Conditions" is not implied. Exposure to "Absolute Max-
imum Ratings" for extended periods may affect device reliability.
Parameter
Symbol
Min
Max
Unit
Supply Input Voltage
V
IN
2.5 18 V
Enable Input Voltage
V
EN
0
18
V
Operating Junction Temperature
T
J
-40
125
o
C
Recommended Operating Conditions
Absolute Maximum Ratings (Note 1)
