Advance Datasheet
High-side Power Distribution Switch with Enable and Flag AP2820
Jul. 2012 Rev 1. 7 BCD Semiconductor Manufacturing Limited
4
Ordering Information
AP2820 -
Circuit Type
Package
Temperature
Range
Condition Part Number Marking ID
Packing
Type
SOIC-8
-40 to 85 °C
Active High
with Auto Discharge
(Continuous 2.0A)
AP2820AM-G1 2820AM-G1 Tube
AP2820AMTR-G1 2820AM-G1 Tape & Reel
Active High
without Auto Discharge
(Continuous 2.0A)
AP2820BM-G1 2820BM-G1 Tube
AP2820BMTR-G1 2820BM-G1 Tape & Reel
-40 to 85 °C
Active Low
with Auto Discharge
(Continuous 2.0A)
AP2820CM-G1 2820CM-G1 Tube
AP2820CMTR-G1 2820CM-G1 Tape & Reel
Active Low
without Auto Discharge
(Continuous 2.0A)
AP2820DM-G1 2820DM-G1 Tube
AP2820DMTR-G1 2820DM-G1 Tape & Reel
-40 to 85 °C
Active High
with Auto Discharge
(Continuous 2.5A)
AP2820EM-G1 2820EM-G1 Tube
AP2820EMTR-G1 2820EM-G1 Tape & Reel
Active High
without Auto Discharge
(Continuous 2.5A)
AP2820FM-G1 2820FM-G1 Tube
AP2820FMTR-G1 2820FM-G1 Tape & Reel
-40 to 85 °C
Active Low
with Auto Discharge
(Continuous 2.5A)
AP2820GM-G1 2820GM-G1 Tube
AP2820GMTR-G1 2820GM-G1 Tape & Reel
Active Low
without Auto Discharge
(Continuous 2.5A)
AP2820HM-G1 2820HM-G1 Tube
AP2820HMTR-G1 2820HM-G1 Tape & Reel
Package
M: SOIC-8
MM: MSOP-8
Condition
For Continuous 2.0A Versions
A: Active High with Auto Discharge
B: Active High without Auto Discharge
C: Active Low with Auto Discharge
D: Active Low without Auto Discharge
For Continuous 2.5A Versions
E: Active High with Auto Discharge
F: Active High without Auto Discharge
G: Active Low with Auto Discharge
H: Active Low without Auto Discharge
G1: Green
TR: Tape & Reel
Blank: Tube
