Advance Datasheet
High-side Power Distribution Switch with Enable and Flag AP2820
Jul. 2012 Rev 1. 7 BCD Semiconductor Manufacturing Limited
15
Typical Application
Note 2: 2.2
μF input capacitor is enough in most application cases.
If the VOUT is short to ground frequently during usage, large size input capacitor is necessary, recommend
22
μF.
Figure 28. Typical Application of AP2820
