AP2401/AP2411
Typical Performance Characteristics
(cont.)
Device Enabled Into Short-Circuit Inrush Current
Full-Load to Short-Circuit
Transient Response
Output Short Circuit T
A
=25°C
V
IN
=5V
R
OUT
=2.5Ω
Device Turns off and Re-enables
Into Current-Limit
Vout
2V/div
Iin
2A/div
FLG
5V/div
Device is latched-off
No-Load to Short-Circuit
Transient Response
Output Short Circuit
T
A
=25°C
V
IN
=5V
Vout
2V/div
Iin
2A/div
FLG
5V/div Device is latched-off
Device Turns off and Re-enables
Into Current-Limit
T
A
=25°C
V
IN
=5V
CL=120µF
R
OUT
=1Ω
Ven
5V/div
Iout
1A/div Iout
0.5A/div
Ven
5V/div
T
A
=25°C
V
IN
=5V
CL=120µF,220uF, 470µF
R
OUT
=5Ω
CL=220µF
CL=470µF
CL=120µF
