AP2401/AP2411
Typical Performance Characteristics
V
EN
90%
V
OUT
T
D(ON)
10%
T
D(OFF)
50% 50%
T
R
10%
90%
T
F
V
EN
90%
V
OUT
T
D(ON)
10%
T
D(OFF)
50% 50%
T
R
10%
90%
T
F
Figure 1 Voltage Waveforms: AP2401 (left), AP2411 (right)
All Enable Plots are for Enable Active Low
Turn-Off Delay and Fall Time
T
A
=25°C
V
IN
=5V
CL=120µF
R
OUT
=2.5Ω
Vout
2V/div
Ven
5V/div
Iin
1A/div
Device Disable
Turn-On Delay and Rise Time
T
A
=25°C
V
IN
=5V
CL=120µF
R
OUT
=2.5Ω
Vout
2V/div
Ven
5V/div
Iin
1A/div
Inrush Current Limit
Device Enable
Turn-Off Delay and Fall Time
T
A
=25°C
V
IN
=5V
CL=1µF
R
OUT
=2.5Ω
Vout
2V/div
Ven
5V/div
Iin
1A/div
Device Disable
Turn-On Delay and Rise Time
T
A
=25°C
V
IN
=5V
CL=1µF
R
OUT
=2.5Ω
Vout
2V/div
Ven
5V/div
Iin
1A/div
Device Enable
