AP2141/ AP2151
Typical Performance Characteristics
(cont.)
Short Circuit Current,
Device Enabled Into Short
500µs/div
Inrush Current
1ms/div
3 Ω Load Connected to Enabled Device
2ms/div
2 Ω Load Connected to Enabled Device
2ms/div
Short Circuit with Blanking Time and Recovery
20ms/div
Power On
1ms/div
I
OUT
200mA/div
I
OUT
200mA/div
V
IN
= 5V
T
A
= +25°C
C
L
= 22µF
V IN = 5V
T A = +25°C
R L = 10 Ω
C
L
= 470µF
C
L
= 220µF
C
L
= 100µF
V FLAG
2V/div
I OUT
500mA/div
V IN = 5V
T A = +25°C
C L = 22µF
I OUT
1A/div
V OUT
5V/div
V IN
5V/div
T A = +25°C
C L = 22µF
R L = 10 Ω
I OUT
200mA/div
V EN
5V/div
V
EN
5V/div
V
EN
5V/div
V IN = 5V
T A = +25°C
C L = 22µF
V IN = 5V
T A = +25°C
C L = 22µF
V FLAG
2V/div
I OUT
500mA/div
V FLAG
5V/div
V FLAG
5V/div
