AP2101/AP2111
Typical Performance Characteristics
(cont.)
Undervoltage Lockout vs Ambient Temperature
1.90
1.95
2.00
2.05
2.10
2.15
-60 -40 -20 0 20 40 60 80 100
Ambient Temperature (°C)
U
n
de
rv
olt
age
Loc
kout
(
V
)
Threshold Trip Current vs Input Voltage
3.08
3.10
3.12
3.14
3.16
3.18
3.20
3.22
3.24
2.8 3.3 3.8 4.3 4.8 5.3
Input Voltage (V)
Thr
es
hold Tr
ip C
u
rr
en
t (
A
)
Current Limit Response vs Peak Current
0
5
10
15
20
25
30
35
40
45
0 2 4 6 8 10 12
Peak Current (A)
C
u
rr
ent
Lim
it R
es
pons
e
(us
)
UVLO Falling
UVLO Rising
TA = +25°C
CL = 68µF
VIN = 5V
TA = +25°C
