AP2101/AP2111
Typical Performance Characteristics
(cont.)
Device Enabled
1ms/div
Device Disabled
1ms/div
UVLO Increasing
1ms/div
UVLO Decreasing
10ms/div
Turn-On Time vs Input Voltage
250
350
450
550
650
750
850
1.5 2 2.5 3 3.5 4 4.5 5 5.5 6
Input Voltage (V)
T
u
rn
-O
n Ti
me
(
u
s)
Turn-Off Time vs Input Voltage
25
30
35
40
45
50
55
1.5 2 2.5 3 3.5 4 4.5 5 5.5 6
Input Voltage (V)
Tur
n-O
ff Ti
m
e
(us
)
Vflag
5V/div
Iout
1A/div
Ven
5V/div
Vout
5V/div
Vflag
5V/div
Iout
1A/div
Ven
5V/div
Vout
5V/div
CL = 1µF
RL = 10Ω
TA = +25°C
CL = 1µF
RL = 10Ω
TA = +25°C
Iout
500mA/div
TA = +25°C
CL = 100µF
RL = 2.5Ω
Vin
2V/div
Iout
500mA/div
TA = +25°C
CL = 100µF
RL = 2.5Ω
Vin
2V/div
VIN = 5V
TA = +25°C
CL = 100µF
RL = 2.5Ω
VIN = 5V
TA = +25°C
CL = 100µF
RL = 2.5Ω
