AP2142/ AP2152
Document number: DS31571 Rev. 6 - 2
8 of 17
www.diodes.com
January 2013
© Diodes Incorporated
AP2142/ AP2152
Typical Performance Characteristics
(cont.)
Channel 1
Short Circuit with Blanking Time and Recovery
20ms/div
Channel 2
Short Circuit with Blanking Time and Recovery
20ms/div
Channel 1 Power On
1ms/div
Channel 2 Power On
1ms/div
Channel 1 UVLO Increasing
1ms/div
Channel 1 UVLO Decreasing
10ms/div
Iout
200mA/div
Vin
2V/div Vin
2V/div
Iout
200mA/div
TA = +25°C
CL = 22µF
RL = 10Ω
TA = +25°C
CL = 22µF
RL= 10Ω
Vin
5V/div
Vflag
5V/div
TA=25°C
CL=22uF
RL=10Ω Iout
200mA/div
Ven
5V/div
Vin
5V/div
Vflag
5V/div
Iout
200mA/div
Ven
5V/div
TA = +25°C
CL = 22µF
RL = 10Ω
Iout
1A/div
Vout
5V/div VIN = 5V
TA = +25°C
CL = 22µF
Vflag
5V/div Vflag
5V/div
Iout
1A/div
Vout
5V/div VIN = 5V
TA = +25°C
CL = 22µF
