AP6015
High Efficiency Step-Down Low Power DC-DC Converter
AP6015 Rev. 3 17 of 18 FEBRUARY 2009
www.diodes.com © Diodes Incorporated
Marking Information
6015XX
( Top View )
Y W X
Part Number
Logo
A~Z : Green
9 8 7 6
1 2 4 5
10
3
MSOP-10L
XX : 18 for 1.8V
25 for 2.5V
33 for 3.3V
Blank for ADJ
Y : Year : 0~9
a~z : 27~52 week; z represents
W : Week : A~Z : 1~26 week;
52 and 53 week
Package Information
(All Dimensions in mm)
(1) Package type: MSOP-10L
2.95/3.05
0.75/0.95
0.0
5/0.15
2.95/3.05
4.8/5.0
0.17/0.27
0.10
0.1/0.2
0.4/0.7
0.25
Gauge plane
0°
/8
°
"A"
DETAIL "A"
1.10Max.
Seting plane
0.5Typ.
C C
10x-0.30
8x-0.50
10x-1.4
Land Pattern Recommendation
(Unit:mm)
1
1
1
4.
4
