Performance Characteristics
(Cont.)
Start Up from V
IN
(V
IN
=5V, V
OUT
=1.8V, I
OUT
=4A) Disable IC (V
IN
=5V, V
OUT
=1.8V, I
OUT
=4A)
Time 4ms/div Time 20
m
s/div
Load Transient Response (V
IN
=5V, V
OUT
=1.8V, I
OUT
=0 to 4A) Synchronizing to External Clock (f
CLOCK
=2MHz)
Time 200
m
s/div Time 400ns/div
Short Circuit Protection (V
IN
=5V, V
OUT
=1.8V, I
OUT
=4A) Short Circuit Recovery (V
IN
=5V, V
OUT
=1.8V, I
OUT
=4A)
Time 4ms/div Time 4ms/div
V
OUT
1V/div
V
IN
2V/div
I
L
2A/div
V
SS
2V/div
V
EN
2V/div
V
OUT
1V/div
V
SS
2V/div
I
L
2A/div
V
OUT(AC)
200mV/div
I
OUT
2A/div
V
CLOCK
2V/div
V
SW
2V/div
V
OUT
1V/div
V
SS
2V/div
V
COMP
0.5V/div
I
L
2A/div
V
OUT
1V/div
V
SS
2V/div
V
COMP
0.5V/div
I
L
2A/div
